HBL2418 Brushless Motor

2418 Brushless Motor is applied to hair clippers. The hair clippers adopt high-performance magnetic brushless motor, which is far superior to brushed motor in service time, working efficiency and using effect. Refer to the parameters for details.

Model：HBL2418
LxWxH(mm)：24.0(D)×18.0(H)
Rated Volts (V)：3.0-24.0
NLSpeed (rpm)：7200-12700
Ld Speed (rpm)：5700-9400
Stall Tq (mNm/A)：140-240
Stall Curr.(A)：1.3-3.9

Consultation

Product Details

Technical Parameters

Model	HBL2418L-01A	HBL2418L-02A
Voltage(V DC)	3.7	24.0
No-Load Speed(rpm)	7200	12700
No-Load Current(A)	0.23	0.1
Rated Speed(rpm)	5700	9400
Rated Current(A)	2.2	0.37
Rated Load(g.cm)	70	60
Rated Load(mN.m)	6.8	5.88
Rated Load(mN.m)	6.8	5.88
Load Power(W)	4.1	5.78
Stall Torque(g.cm)	140	240
Stall Torque(mN.m)	13.72	23.5
Stall Torque(mN.m)	13.72	23.5
Stall Current(A)	3.9	1.3
